Original price was: $382.00.$113.85Current price is: $113.85.
| UPC: | 722856041876 | Weight: | 15 LB |
| Packaged Length: | 13.25 IN | Packaged Width: | 7 IN |
| Packaged Height: | 6.94 IN |
| Output HP: | 0.50 Hp | Output KW: | 0.37 kW |
| Frequency: | 60 Hz | Voltage: | 208-230 V |
| Current: | 2.9-2.6 A | Speed: | 1075 rpm |
| Service Factor: | 1 | Phase: | 1 |
| Efficiency: | 65.8 % | Power Factor: | 95.6 |
| Duty: | Continuous | Insulation Class: | B |
| Design Code: | NO DESIGN CODE | KVA Code: | A |
| Frame: | 48Z | Enclosure: | Open Air Over |
| Thermal Protection: | Automatic Lock Rotor Only | Ambient Temperature: | 60 °C |
| Drive End Bearing Size: | 6203 | Opp Drive End Bearing Size: | 6203 |
| UL: | Recognized | CSA: | Y |
| CE: | N | IP Code: | 10 |
| Electrical Type: | Permanent Split Capacitor | Starting Method: | Across The Line |
| Poles: | 6 | Rotation: | Selective Counterclockwise |
| Mounting: | Resilient Ring – Extended Studs | Motor Orientation: | HORIZONTAL |
| Drive End Bearing: | BALL | Opp Drive End Bearing: | BALL |
| Frame Material: | Rolled Steel | Shaft Type: | Single Special Extension |
| Overall Length: | 4.75 in | Frame Length: | 4.25 in |
| Shaft Diameter: | 0.500 in | Shaft Extension: | 4.75 in |
| Assembly/Box Mounting: | F1 ONLY |
